SpringBoot使用Canal做MySQL与Redis的数据同步

从现在开始，努力学习吧！本文《SpringBoot使用Canal做MySQL与Redis的数据同步》主要讲解了MySQL、Redis、spring等等相关知识点，我会在golang学习网中持续更新相关的系列文章，欢迎大家关注并积极留言建议。下面就先一起来看一下本篇正文内容吧，希望能帮到你！

环境：Springboot2.7.8 + MySQL8

1 环境准备

master: 192.168.2.129

slave: 192.168.2.130

使用Docker安装MySQL，这里Docker安装省略，网上一堆教程。

Docker安装完成后，安装MySQL。

安装MySQL

步骤1：

[root@node150 kafka]# mkdir -p /root/software/mysql/conf /root/software/mysql/data [root@node150 kafka]# chmod -R 777 /root/software/mysql/

步骤2：

进入/root/software/mysql/conf 创建my.cnf 内容如下：

[client] #socket = /usr/mysql/mysqld.sock default-character-set = utf8mb4 [mysqld] #pid-file = /var/run/mysqld/mysqld.pid #socket = /var/run/mysqld/mysqld.sock #datadir = /var/lib/mysql #socket = /usr/mysql/mysqld.sock #pid-file = /usr/mysql/mysqld.pid datadir = /var/lib/mysql character_set_server = utf8mb4 collation_server = utf8mb4_bin secure-file-priv= NULL # Disabling symbolic-links is recommended to prevent assorted security risks symbolic-links=0 # Custom config should go here !includedir /etc/mysql/conf.d/

步骤3：

docker run --name mysql8 --restart=always --privileged=true -v /root/software/mysql/conf/my.cnf:/etc/mysql/my.cnf -v /root/software/mysql/data:/var/lib/mysql -v /etc/localtime:/etc/localtime:ro -p 3306:3306 -e MYSQL_ROOT_PASSWORD=123123 -d mysql --lower_case_table_names=1

完成分别在129，130上完成上面操作。

2 主从配置

129.168.2.129作为master节点，修改my.cnf配置，追加下面配置：

binlog_format=MIXED log-bin=mysql-bin server-id=1

129.168.2.130作为slave节点，修改my.cnf配置，追加下面配置：

log-bin=mysql-bin server-id=2

修改完配置后分别重启mysql

3 配置从节点

3.1 查看master状态

mysql> show master status; +------------------+----------+--------------+------------------+-------------------+ | File | Position | Binlog_Do_DB | Binlog_Ignore_DB | Executed_Gtid_Set | +------------------+----------+--------------+------------------+-------------------+ | mysql-bin.000001 | 156 | | | | +------------------+----------+--------------+------------------+-------------------+ 1 row in set (0.00 sec)

这里的File，Position列再配置从节点时需要用到。

3.2 配置从节点

CHANGE MASTER TO MASTER_HOST='192.168.2.129', MASTER_PORT=3306, MASTER_USER='root', MASTER_PASSWORD='123123', master_log_file='mysql-bin.000003', master_log_pos=156, master_connect_retry=60, GET_MASTER_PUBLIC_KEY=1;

执行上面的命令如果报错如下：

This operation cannot be performed with a running slave io thread; run STOP SLAVE IO_THREAD FOR CHANNEL '' first.

这时需要执行stop slave

注意：上面的mysql-bin.000003 是首次配置的，如果master节点重启了，这个文件会递增变为mysql-bin.000004，这时我们的从节点会自动连上这mysql-bin.000004

查看从节点状态：

mysql> show slave status\G *************************** 1. row *************************** Slave_IO_State: Waiting for source to send event Master_Host: 192.168.2.129 Master_User: root Master_Port: 3306 Connect_Retry: 60 Master_Log_File: mysql-bin.000005 Read_Master_Log_Pos: 156 Relay_Log_File: 85acaa370429-relay-bin.000014 Relay_Log_Pos: 371 # 该文件会自动与master节点同步 Relay_Master_Log_File: mysql-bin.000005 # 主要看这里的两个Running是否为Yes Slave_IO_Running: Yes Slave_SQL_Running: Yes Replicate_Do_DB: Replicate_Ignore_DB: Replicate_Do_Table: Replicate_Ignore_Table: Replicate_Wild_Do_Table: Replicate_Wild_Ignore_Table: Last_Errno: 0 Last_Error: Skip_Counter: 0 Exec_Master_Log_Pos: 156 Relay_Log_Space: 755 Until_Condition: None Until_Log_File: Until_Log_Pos: 0 Master_SSL_Allowed: No Master_SSL_CA_File: Master_SSL_CA_Path: Master_SSL_Cert: Master_SSL_Cipher: Master_SSL_Key: Seconds_Behind_Master: 0 Master_SSL_Verify_Server_Cert: No Last_IO_Errno: 0 Last_IO_Error: Last_SQL_Errno: 0 Last_SQL_Error: Replicate_Ignore_Server_Ids: Master_Server_Id: 1 Master_UUID: 71bb9106-a9a9-11ed-9031-0242ac110002 Master_Info_File: mysql.slave_master_info SQL_Delay: 0 SQL_Remaining_Delay: NULL Slave_SQL_Running_State: Replica has read all relay log; waiting for more updates Master_Retry_Count: 86400 Master_Bind: Last_IO_Error_Timestamp: Last_SQL_Error_Timestamp: Master_SSL_Crl: Master_SSL_Crlpath: Retrieved_Gtid_Set: Executed_Gtid_Set: Auto_Position: 0 Replicate_Rewrite_DB: Channel_Name: Master_TLS_Version: Master_public_key_path: Get_master_public_key: 1 Network_Namespace: 1 row in set, 1 warning (0.00 sec)

3.3 测试

在主节点上执行创建数据库，建表等操作都会自动同步到slave节点上。

4 创建Canal

docker run --name canal -p 11111:11111 -v /opt/canal/conf:/home/admin/canal-server/conf -v /opt/canal/logs:/home/admin/canal-server/logs -d canal/canal-server

5 Springboot整合Canal

添加依赖

org.springframework.bootspring-boot-starter-data-redisorg.springframework.bootspring-boot-starter-webtop.javatoolcanal-spring-boot-starter1.2.1-RELEASE

配置文件

spring: redis: host: localhost port: 6379 password: 123123 database: 8 lettuce: pool: maxActive: 8 maxIdle: 100 minIdle: 10 maxWait: -1 --- canal: server: 192.168.2.130:11111 destination: redis #可设置*个，逗号隔开，对应需要创建*文件夹，且文件夹下有instance.properties文件

数据模型

public class Users { private Integer id ; private String name ; private Integer age ; @Override public String toString() { return "Users [id=" + id + ", name=" + name + ", age=" + age + "]"; } }

具体服务组件

@Component @CanalTable(value = "users") public class UserServiceImpl implements EntryHandler { private static final Logger logger = LoggerFactory.getLogger(UserServiceImpl.class); private final StringRedisTemplate stringRedisTemplate ; public UserServiceImpl(StringRedisTemplate stringRedisTemplate) { this.stringRedisTemplate = stringRedisTemplate ; } @Override public void insert(Users user) { logger.info("新增数据为{}", user); try { this.stringRedisTemplate.opsForValue().set("users:" + user.getId(), new ObjectMapper().writeValueAsString(user)) ; } catch (JsonProcessingException e) { e.printStackTrace(); } } @Override public void update(Users before, Users after) { logger.info("原来数据为{}", before); logger.info("更新数据为{}", after); try { this.stringRedisTemplate.opsForValue().set("users:" + after.getId(), new ObjectMapper().writeValueAsString(after)) ; } catch (JsonProcessingException e) { e.printStackTrace(); } } @Override public void delete(Users user) { logger.info("删除的数据为{}", user); this.stringRedisTemplate.delete("users:" + user.getId()) ; } }

以上通过增，删，改数据就能同步到Redis中了。
